Máy photocopy Ricoh bị kẹt giấy.
Nội Dung
Kiểm tra trong trong trường hợp nào?. Sử dụng code này khi khách hàng báo kẹt giấy nhưng qua thì không thấy kẹt giấy trên máy photocopy.
Lưu ý: Để kiểm tra một cách chính xác chúng ta cần biết rõ từng bộ phận máy tên gì và nằm ở vị trí như thế nào thì việc sử dụng code này dễ dàng hơn.
Có 2 vị trí cần kiểm tra là ADF và thân máy
Kiểm tra ADF
- Đầu tiên vào code 7508 (hiển thị code kẹt giấy – ở đây sẽ hiện 10 lỗi kẹt giấy gần nhất)
- Sau đó vào code 7505 (thông qua code kẹt cho ta biết vị trí kẹt nằm ở bộ phận nào)
Ví dụ:
7508* | Original Jam History |
Displays the original jam history of the transfer unit in groups of 10, starting with the most recent 10 jams. Display contents are as follows: CODE is the SP7-505-*** number. SIZE is the paper size code in hex. (See “Paper Size Hex Codes” below.) TOTAL is the total jam error count (SP7-003) DATE is the date the previous jam occurred |
Sample Display: CODE: 007 (code ket giấy) SIZE: 05h Khổ giấy kẹt (đọc trong tài liệu) TOTAL: 0000334 (số lần kẹt xem trong 7003) DATE: Mon Mar 15 11:44:50 2000 (giờ, ngày)Khung này hiển thị mã code kẹt giấy là |
75081* kẹt lần 1 | Latest |
75082* lần 2 | Latest 1 |
75083* | Latest 2 |
75084* | Latest 3 |
75085* | Latest 4 |
75086* | Latest 5 |
75087* | Latest 6 |
75088* | Latest 7 |
75089* | Latest 8 |
750810* | Latest 9 |
ServiceTables:
Total Original Jam by Location | Display range: 0000~9999 | 7505* |
Displays the total number of original jams by location. These jams occur when the original does not activate the sensors. Note: A “Check In” failure occurs when the paper fails to activate the sensor at the precise time. A “Check Out” failure occurs when the paper remains at the sensor for longer than the prescribed time and causes a jam. The 3rd column in the table below tells you the correct component name used in the service manual. |
||
Operation Panel Display | Service Manual Name | |
1 | At Power On | — |
3 | Registration Sensor Check In Failure | Skew Correction Sensor |
4 | Nip-in Sensor Check In Failure | Interval Sensor |
5 | Registration Sensor (On Check) | — |
6 | Relay Sensor (On Check) | |
7 | Inverter Sensor (On Check) | |
53 | Registration Sensor Check Out Failure | Skew Correction Sensor |
54 | Nip-in Check Out Failure | Interval Sensor |
55 | Registration Sensor (Off Check) | |
56 | Relay Sensor (Off Check) | |
57 | Inverter Sensor (Off Check) |
Thì ở đây sau khi chúng ta vào code 7508 thì vị trị code kẹt giấy là 007 (màu đỏ) và chúng ta qua code và dò vị trí của code là 007 thì kẹt giấy nằm ở ví 7(Màu đỏ)
Kiểm tra thân máy
- Đầu tiên vào code 7507 (hiển thị code kẹt giấy – ở đây sẽ hiện 10 lỗi kẹt giấy gần nhất)
- Sau đó vào code 7504 (thông qua code kẹt cho ta biết vị trí kẹt nằm ở bộ phận nào)
7507* | Copy Jam History (Transfer Sheet) | |
Displays the copy jam history of the transfer unit in groups of 10, starting with the most recent 10 jams. Display contents are as follows: CODE is the SP7-505-*** number. SIZE is the paper size code in hex. (See “Paper Size Hex Codes” below.) TOTAL is the total jam error count (SP7-003) DATE is the date the previous jam occurred |
Sample Display:
CODE: 007 SIZE: 05h TOTAL: 0000334 DATE: Mon Mar 15 11:44:50 2000 |
|
7507 1* | Latest | |
7507 2* | Latest 1 | |
7507 3* | Latest 2 | |
7507 4* | Latest 3 | |
7507 5* | Latest 4 | |
7507 6* | Latest 5 | |
7507 7* | Latest 6 | |
7507 8* | Latest 7 | |
7507 9* | Latest 8 | |
7507 10* | Latest 9 |
ServiceTables:
Paper Jam Counter by Jam Location | Display range: 0000~9999 | 7504* |
Displays the total number of copy jams by location. A “Paper Late” error occurs when the paper fails to activate the sensor at the precise time. A “Paper Lag” paper jam occurs when the paper remains at the sensor for longer than the prescribed time. |
||
Error No. | Error | |
1* | At Power On | |
3* | Tray 1: On | |
4* | Tray 2: On | |
5* | Tray 3/LCT: ON | |
6* | Tray 4: On | |
7* | External Tray: On | |
8* | Registration: ON | |
9* | External Tray: ON | |
10* | Internal Tray: ON | |
13* | Duplex Exit 2: ON | |
14* | Duplex Exit 3: ON | |
16* | Exit 1: Off | |
17* | — | |
18* | — | |
19* | Ent. Duplex 1: Off | |
23* | Exit Duplex: Off | |
24* | — | |
25* | Finisher Entrance | |
26* | Finisher Proof Tray | |
27* | Finisher Shift Tray | |
28* | Finisher Stapler | |
29* | Finisher Exit | |
30* | Mailbox Entrance | |
31* | Mailbox Proof Tray | |
32* | Mailbox Relay | |
33* | Mailbox MBX | |
35* | Booklet FIN Entrance | |
36* | Booklet FIN Transport | |
37* | Booklet FIN Early | |
38* | Booklet FIN Staple |
Tương tự như cách kiểm tra của ADF.
Hy vọng bài viết trên sẽ giúp ích cho bạn trong việc bảo trì và sửa chữa máy photocopy.
